Wallmax Open Face Wall Pack-80W 120-277V CCT Selectable 3000K/4000K/5000K Controls Ready Bronze (WPOP80U-CSBCR) Maxlite 104901

$139.03

Availability : In Stock

Product Type :

Vendor : Maxlite

SKU : WPOP80U-CSBCR

" Full case qty = 1Maxlite 104901 Wallmax Open Face Wall Pack-80W 120-277V CCT Selectable 3000K/4000K/5000K Controls Ready Bronze (WPOP80U-CSBCR)The new generation of WallMax Open Face LED Wall Packs provides flexibility for distributors and contractors with field-selectable CCTs wattages (55W and 120W models) and field-installable controls. The housing has been...


"Maxlite

Full case qty = 1

Maxlite 104901 Wallmax Open Face Wall Pack-80W 120-277V CCT Selectable 3000K/4000K/5000K Controls Ready Bronze (WPOP80U-CSBCR)

The new generation of WallMax Open Face LED Wall Packs provides flexibility for distributors and contractors with field-selectable CCTs wattages (55W and 120W models) and field-installable controls. The housing has been enlarged to cover HID fixture footprints and accommodate battery backup in all sizes. The Wall Packs feature-controls-ready receptacle compatible with c-Max controls. The simple plug-and-play sensor receptacle enables c-Max control nodes to be added at the time of installation or in the future. as well as allowing for future control upgrades without changing the fixture. The receptable is located at the bottom of the fixture and looks through-window which minimizes the impact on the fixture aesthetics. -cover is included to hide the window when controls are not used.

Specifications

Brand Maxlite Manufacturer Part Number WPOP80U-CSBCR
Manufacturer Code 104901 UPC Code #767627000980
GTIN #767627000980 Technology LED
Case Pack 1 Equivalent Watts 400W Metal Halide
Warranty 10 Year Warranty cULus Listed Yes
DLC DLC Premium Wattage 80
Voltage 120 to 277 Lumens 10714.2
CRI 80 Beam Angle (Degrees) 110
Control 0-10V Dimming Average Life (Hours) 54000
Lumens Per Watt 1352 Ballast 9999
Kelvin Temperature 3000-5000 Adjustable
WPOP80U-CSBCR  - Spec Sheet

Dimensions

Length (in) 17.87 Height (in) 9.06
Width (in) 9.61 Product Weight (lbs) 9.5
"
