Square D FHL36035 3 Pole Circuit Breaker

$981.82

Availability : In Stock

Product Type :

Vendor : Square D

SKU : FHL36035

Square D FHL36035 3 Pole Circuit Breaker The Square D FHL36035 is a 3 Pole thermal magnetic molded case circuit breaker with a current rating of 35 Amps and a voltage rating of 600VAC. It has an interrupting rating of 25kAIC at 480V. The FHL36035 has an unit mounting type...


Square D FHL36035 3 Pole Circuit Breaker

The Square D FHL36035 is a 3 Pole thermal magnetic molded case circuit breaker with a current rating of 35 Amps and a voltage rating of 600VAC. It has an interrupting rating of 25kAIC at 480V. The FHL36035 has an unit mounting type and includes long time and instantaneous trip functions.



Specifications

Brand Square D
Series FHL
Amperage 35
Voltage 600VAC
Poles 3
Phase 3
Mounting Type Unit
Approval HACR, CSA, UL
Interrupting Rating 25kAIC at 480V
Frame Type FHL
Connection Type Feed-Thru
Protection Thermal Magnetic
Functions Long Time and Instantaneous Trip
Terminal Connection Line and Load Side Lug
Standards RoHS/REACh
Mpn FHL36035
Upc 785901076223
