Square D FHL36030-1212 3 Pole Circuit Breaker
$883.64
Availability : In Stock
Product Type :
Vendor : Square D
SKU : FHL36030-1212
Square D FHL36030-1212 3 Pole Circuit Breaker The Square D FHL36030-1212 is a 3 Pole thermal magnetic molded case circuit breaker with a current rating of 30 Amps and a voltage rating of 600V. It has an interrupting rating of 25kAIC at 480V. The FHL36030-1212 has a feed-thru connection type...
Square D FHL36030-1212 3 Pole Circuit Breaker
The Square D FHL36030-1212 is a 3 Pole thermal magnetic molded case circuit breaker with a current rating of 30 Amps and a voltage rating of 600V. It has an interrupting rating of 25kAIC at 480V. The FHL36030-1212 has a feed-thru connection type and includes long time and instantaneous trip functions.
Specifications
Brand | Square D |
Series | FHL |
Amperage | 30 |
Voltage | 600 |
Poles | 3 |
Phase | 3 |
Interrupting Rating | 25kA@480V |
Frame Type | F |
Connection Type | Feed-Thru |
Protection | Thermal Magnetic |
Functions | LI - Long-Time and Instantaneous |
Terminal Connection | Line and Load Side Lug |
Mpn | FHL36030-1212 |
Upc | 785901076209 |
Gtin | 785901076209 |
