Square D FA36015-1021 3 Pole Circuit Breaker

$1,325.46

Availability : In Stock

Product Type :

Vendor : Square D

SKU : FA36015-1021

Square D FA36015-1021 3 Pole Circuit Breaker The Square D FA36015-1021 is a 3 Pole thermal magnetic molded case circuit breaker with a current rating of 15 Amps and a voltage rating of 600V. It has an interrupting rating of 18kAIC at 480V. The FA36015-1021 has a I-Line mounting type...

Product Details

Square D FA36015-1021 3 Pole Circuit Breaker

The Square D FA36015-1021 is a 3 Pole thermal magnetic molded case circuit breaker with a current rating of 15 Amps and a voltage rating of 600V. It has an interrupting rating of 18kAIC at 480V. The FA36015-1021 has a I-Line mounting type and includes long time and instantaneous trip functions.

Specifications

Brand	Square D
Series	FA
Amperage	15
Voltage	600V
Poles	3
Phase	3
Mounting Type	I-Line
Approval	UL, CSA
Interrupting Rating	18kAIC at 480V
Frame Type	F
Connection Type	Plug-In
Protection	Thermal Magnetic
Functions	Long Time and Instantaneous Trip
Terminal Connection	Line and Load Side Lug
Standards	HACR, RoHS, REACh
Temperature Rating	40 °C
Mpn	FA36015-1021
Gtin	785901112648
