Square D EGB34040SA 3 Pole Circuit Breaker
$1,811.57
Availability : In Stock
Product Type :
Vendor : Square D
SKU : EGB34040SA
Square D EGB34040SA 3 Poles Circuit Breaker Square D 3 poles circuit breaker features a thermal magnetic molded case for extra protection. The circuit breaker has a current rating of 40 amps with a voltage rating of 480 v. It has an interrupt rating of 35kAIC@480V. Specifications: Manufacturer: Square D...
Square D EGB34040SA 3 Poles Circuit Breaker
Square D 3 poles circuit breaker features a thermal magnetic molded case for extra protection. The circuit breaker has a current rating of 40 amps with a voltage rating of 480 v. It has an interrupt rating of 35kAIC@480V.
Specifications:
- Manufacturer: Square D
- Cat. No: EGB34040SA
- Alternate Part No: EGB34040SA
- Product Type: Circuit Breaker
- Trip Unit Type: Thermal-magnetic
- Series: EGB
- Frame Type: EGB
- Type: EGB
- Phase: 3
- Number Of Poles: 3
- Voltage Rating: 480 V
- Amperage Rating: 40 A
- Connection: Bolt-On
- Functions: Long Time and Instantaneous Trip
- Interrupt Rating: 35kAIC@480V
- Electrical Connection: Lugs aluminium
- AWG guage: AWG 12, AWG 2/0 aluminium, AWG 14, AWG 2/0 copper
- Size: 5.66 Inch H x 3.92 Inch W x 4.05 Inch D
- Mounting: Bolt-On
- Approval: UL
- Authentic Square D Product
Specifications
Brand | Square D |
Series | EGB |
Amperage | 40 |
Voltage | 480 |
Poles | 3 |
Phase | 3 |
Mounting Type | Bolt-On |
Approval | UL |
Interrupting Rating | 35kAIC@480V |
Frame Type | EGB |
Connection Type | Bolt-On |
Protection | Thermal Magnetic |
Functions | Long Time and Instantaneous Trip |
Length (in) | 4.05 |
Width (in) | 3.92 |
Height (in) | 5.66 |
Wire Gauge | AWG 12, AWG 2/0 aluminium, AWG 14, AWG 2/0 copper |
Mpn | EGB34040SA |
Upc | 785901285182 |
Gtin | 785901285182 |
