Square D EDB34070SA 3 Pole Circuit Breaker
$1,376.05
Availability : In Stock
Product Type :
Vendor : Square D
SKU : EDB34070SA
Square D EDB34070SA 3 Pole Circuit Breaker The Square D EDB34070SA is a 3 Pole thermal magnetic molded case circuit breaker with a current rating of 70 Amps and a voltage rating of 480Y/277VAC. It has an interrupting rating of 18kA at 277/480VAC. The EDB34070SA has a bolt-on mounting type...
Square D EDB34070SA 3 Pole Circuit Breaker
The Square D EDB34070SA is a 3 Pole thermal magnetic molded case circuit breaker with a current rating of 70 Amps and a voltage rating of 480Y/277VAC. It has an interrupting rating of 18kA at 277/480VAC. The EDB34070SA has a bolt-on mounting type and includes long time and instantaneous trip functions.
Specifications
Brand | Square D |
Series | EDB |
Amperage | 70 |
Voltage | 480Y/277VAC |
Poles | 3 |
Phase | 3 |
Mounting Type | Bolt-On |
Approval | CULus |
Interrupting Rating | 18kA at 277/480VAC |
Frame Type | EDB |
Protection | Thermal Magnetic |
Functions | Long Time and Instantaneous Trip |
Terminal Connection | Lug |
Wire Gauge | AWG 12 to 2/0 Aluminum, AWG 14 to 2/0 Copper |
For Use With | NF Panelboards |
Standards | RoHS |
Temperature Rating | 104°F (40°C) |
Circuit Breaker Type | Shunt Trip |
Actuator Type | Toggle |
Mpn | EDB34070SA |
Gtin | 785901112846 |
