Square D BJA36090 3 Pole Circuit Breaker
$1,146.60
Availability : In Stock
Product Type :
Vendor : Square D
SKU : BJA36090
Square D BJA36090 3 Poles Circuit Breaker Square D/Schneider Electric 3 Poles Circuit Breaker features a thermal magnetic molded case for extra protection. The circuit breaker has a current rating of 90 amps with a voltage rating of 600 v. It has an interrupt rating of 65kA@480V. Specifications: Manufacturer: Square...
Square D BJA36090 3 Poles Circuit Breaker
Square D/Schneider Electric 3 Poles Circuit Breaker features a thermal magnetic molded case for extra protection. The circuit breaker has a current rating of 90 amps with a voltage rating of 600 v. It has an interrupt rating of 65kA@480V.
Specifications:
- Manufacturer: Square D/Schneider Electric
- Cat. No: BJA36090
- Alternate Part No: BJA36090
- Product Type: Circuit Breaker
- Trip Unit Type: Thermal-Magnetic
- Frame Type: BJA
- Type: BJA
- Phase: 3
- Number Of Poles: 3
- Voltage Rating: 600 V
- Amperage Rating: 90 A
- Connection: I-Line Style Plug-In
- Functions: LI - Long-Time and Instantaneous
- Interrupt Rating: 65kA@480V
- Frame Size: B
- Electrical Connection: I-Line Connection Line and Lugs Load
- Terminals: Load Side Mechanical Lug
- AWG Gauge: AWG 14, AWG 2/0 Aluminium/Copper
- Size: 5.39 Inch H x 3.19 Inch W x 3.50 Inch D
- Mounting: I-Line
- Approval: UL, IEC, CCC, EAC, CSA, NOM
- Brand: Square D[R]
- Authentic Square D/Schneider Electric Product
Specifications
Brand | Square D |
Series | BJA |
Amperage | 90 |
Voltage | 600 |
Poles | 3 |
Phase | 3 |
Mounting Type | I-Line |
Approval | UL, IEC, CCC, EAC, CSA, NOM |
Interrupting Rating | 65kA@480V |
Frame Type | BJA |
Connection Type | I-Line Style Plug-In |
Protection | Thermal Magnetic |
Functions | LI - Long-Time and Instantaneous |
Terminal Connection | Load Side Mechanical Lug |
Length (in) | 3.5 |
Width (in) | 3.19 |
Height (in) | 5.39 |
Wire Gauge | AWG 14, AWG 2/0 Aluminium/Copper |
Mpn | BJA36090 |
Upc | 3606481185914 |
Gtin | 3606481185914 |
