Square D BGL36100 3 Pole Circuit Breaker

$1,392.00

Availability : In Stock

Product Type :

Vendor : Square D

SKU : BGL36100

Square D BGL36100 3 Pole Circuit Breaker The Square D BGL36100 is a 3 Pole thermal magnetic molded case circuit breaker with a current rating of 100 Amps and a voltage rating of 600V. It has an interrupting rating of 18kA. The BGL36100 has a din rail mounting type and...

Product Details

Square D BGL36100 3 Pole Circuit Breaker

The Square D BGL36100 is a 3 Pole thermal magnetic molded case circuit breaker with a current rating of 100 Amps and a voltage rating of 600V. It has an interrupting rating of 18kA. The BGL36100 has a din rail mounting type and includes long time and instantaneous functions.

Specifications

Brand	Square D
Series	BGL
Amperage	100
Voltage	600
Poles	3
Phase	3
Mounting Type	Unit
Approval	UL, IEC, CCC, EAC, CSA, NOM
Interrupting Rating	18kA
Frame Type	B Frame
Connection Type	Line/Load: Lug Terminal
Protection	Thermal Magnetic
Functions	LI - Long-Time and Instantaneous
Terminal Connection	Everlink Lug Both Ends
Length (in)	3.15
Width (in)	3.19
Height (in)	5.39
For Use With	Electrical Distribution Equipment, Industrial Control Panels
Temperature Rating	-13…158 °F (-25…70 °C)
Max Wire Size	2 AWG, 3 AWG
Mpn	BGL36100
Upc	3606481154132
Gtin	3606481154132
