205 Series Metal Halide Die Cast Aluminum Sportslighter with Lamp

Name: 205 Series Metal Halide Die Cast Aluminum Sportslighter with Lamp
Brand: Flood Lights
SKU: ESW-TL205-FLD-MH
Price: 330.0 USD
Availability: InStock

$330.00

Availability : In Stock

Product Type : Flood Lights

Vendor : Flood Lights

SKU : ESW-TL205-FLD-MH

PRODUCT OVERVIEW The ESW-TL205 Series is ideal for outbuildings, arenas, parks, sports fields, sign illumination, and other areas where general floodlighting is necessary. Available with Metal Halide lamps for superior illumination. Features Durable, die-cast aluminum enclosure with an architectural bronze powder coated finish Standard 19" spun aluminum reflector provides 5H...

400 Watt

400 Watt Pulse Start (Add $25)

1000 Watt MH (Add $40)

1000 Watt PSMH (Add $70)

None

Large Handle Yoke (Add $40)

Quantity

Product Details

PRODUCT OVERVIEW
The ESW-TL205 Series is ideal for outbuildings, arenas, parks, sports fields, sign illumination, and other areas where general floodlighting is necessary. Available with Metal Halide lamps for superior illumination.

Features

Durable, die-cast aluminum enclosure with an architectural bronze powder coated finish

Standard 19" spun aluminum reflector provides 5H x 4V light distribution, other reflector options are available

Fully sealed and gasketed, wet location listed

Corrosion-resistant hardware

Lamp is protected by a high-impact, heat resistant tempered glass lens

Available with Metal Halide, Pulse Start Metal Halide or High Pressure Sodium lamps from 400 to 1500 watts

9/16 mounting bolt is standard, optional mounts are available

Angle indicators on adjustable socket make aiming easy

Buy American Option Available

Construction
The TL205 Series features a durable, corrosion-resistant, die-cast aluminum lamp and ballast enclosure with an architectural bronze powder coated finish. Standard 19" spun aluminum reflector provides 5H x 4V light distribution; four other optional NEMA type reflectors are available. Enclosure is fully sealed and gasketed, and is Wet Location Listed for outdoor use and includes corrosion-resistant hardware. The lamp is protected by a high-impact, heat-resistant tempered glass lens.

Lamps and Ballasts
High Pressure Sodium: ED37 or BT56 type lamps in 400 or 1000 watts, utilizing a mogul base, glazed porcelain socket pulse rated for 4KV with a CWA type ballast rated for a minimum operating temperature of -30OC (-22OF) and Multi-tap (120/208/240/277VAC) or 480VAC input.

Metal Halide: BT56 type lamps in 1000 or 1500 watts, utilizing a mogul base, glazed porcelain socket pulse rated for 4KV with a CWA ballast rated for a minimum operating temperature of -30OC (-22OF) and Multi-tap (120/208/240/277VAC) or 480VAC input.

Pulse Start Metal Halide: ED37 or BT56 type lamps from 450 to 1000 watts, utilizing a mogul base, glazed porcelain socket pulse rated for 4KV with a CWA ballast rated for a minimum operating temperature of -30OC (-22OF) and Multi-tap (120/208/240/277VAC) or 480VAC input.

Warranty
Any housing component that fails due to manufacturer's defect is guaranteed for two years from time of shipment. Ballasts, Capacitors, and Ignitors are warrantied for one year from time of shipment. Warranty does not apply to damages caused by improper installation, abuse, fire or acts of God. Lamp is not covered by manufacturer's warranty.
