Incandescent Vaporproof Security Lighting

$39.00

Availability : In Stock

Product Type : Wet Location Fixtures

Vendor : Wet Location Fixtures

SKU : ESW-801-VP

PROUDCT OVERVIEW • Heavy duty, die-cast aluminum housing • Textured grey, paintable powdercoated finish • Impact and heat-resistant clear glass globe, optional frosted glass globe is available • UL listed for wet locations, fully sealed and gasketed housing • Complies with UL Standard 1598, provides protection for the lamp, socket,...


PROUDCT OVERVIEW
• Heavy duty, die-cast aluminum housing
• Textured grey, paintable powdercoated finish
• Impact and heat-resistant clear glass globe, optional frosted glass globe is available
• UL listed for wet locations, fully sealed and gasketed housing
• Complies with UL Standard 1598, provides protection for the lamp, socket, and wiring from water, corrosive fumes, non-combustible dusts, non-explosive vapors & gases
• Porcelain medium-based socket, rated for 600VAC/660W

PRODUCT SPECIFICATIONS
The ESW 801 Series features a heavy duty, diecast aluminum housing with a paintable textured grey powdercoated finish. The cast aluminum guard screws on to the housing and is secured with a headless set screw. The ESW 801 is UL Listed for wet locations and complies with UL Standard 1598 for non-hazardous locations where the luminaire must provide protection for the lamp, socket, and wiring from water, corrosive fumes, non-combustible dusts, non-explosive vapors & gases. The lamp is protected by a heat and impact resistant clear glass globe that is standard, a frosted glass globe can be specified.

ELECTRONICS
The ESW 801 utilizes a porcelain medium base socket rated for 600VAC 660W with 8” high temperature wire leads. Two housing sizes are available, a maximum 200 watt unit and a maximum 300w unit.

INSTALLATION
The ESW 801 is available in both wall mount and ceiling mount styles. A weatherproof junction box with both ½” or ¾” NPT hubs and rugged mounting tabs is included with both styles. A full line of accessories with matching grey textured powdercoated finish is available to modify the fixtures for many different applications including pendant mounts, shades, wire guards, and glass globes.

WARRANTY
Any housing component that fails due to manufacturer ’s defect is guaranteed for two years from time of shipment. Ballasts, Capacitors, and Ignitors are warrantied for one year from time of shipment. Warranty does not apply to damages caused by improper installation, abuse, fire or acts of God. Lamp is not covered by manufacturer’s warranty.
